Reolink Keen™

World's #1 100% Wire-Free Pan & Tilt Security Camera

Battery-Powered
Two-Way Audio
PIR Motion Sensor
Pan & Tilt

Pan-Tilt, Reach More and See More

Capable of rotating 355° horizontally and 140° vertically, Reolink KEEN Ranger PT, the world’s first 4G cellular wire-free battery PT trail camera, expands your field of view to a new height, just with one wildlife camera.

PIR Motion Sensor — Smart & Accurate Alerts

External PIR sensor is sensitive to human or objects radiating infrared energy instead of moving leaves or trees. Reolink Keen™ motion activated home surveillance camera with battery alerts you in real-time, with less false alarms.

Flexible PIR motion alert could be disabled to reduce unwanted alerts, or being always on to watch your place keenly 24/7.

Emails

Email motion snapshots

APP

Push notification to your mobile device

Voice Alert

An alarm will sound automatically when motion is detected

SD Card (Optional)

With built-in SD card slot, record & save motion videos to an SD card

Choose the right microSD card

1080p Full HD & Night Vision

Reolink Keen™ captures exceptionally crisp 1080p HD images, sharper and clearer than those of 720p cameras; meanwhile, it delivers more fluid and crystal videos. Once alerted by human movement, Reolink Keen™ will be on it right away! With 40ft night vision, Reolink Keen™ scouts out keenly even in the dark.

Day
Night

Listen & Talk — Interactive

Two-way audio function enables you to listen to what’s going on inside your house, and not just talk to your loved ones, but warn verbally any uninvited, even when you are miles away.

View Live Anywhere, Even On the Go

Control has never been so easy with free Reolink App and Client! View your family and home anywhere and anytime via your iOS and Android smartphones, or through a Windows or Mac computer! Even when you are in your office or travelling, you can check what’s happening to your home/business on the go!

Free Firmware Update — Easy, Quick and Flexible

Reolink firmware update for IP security cameras is very easy – download firmware on the firmware page and update the firmware on the client software. All is free! Learn More

*Data based on internal lab testing.

Comparison

What’s in the Box & Setup Guide (with Video) What's in the Box

*The data on the pages above are obtained under specific test conditions. Actual use may vary.

Specifications

Hardware
Features

Image Sensor

1/2.7" CMOS Sensor

Display Resolution

1920x1080 (2.0 Megapixels)

Lens

f=4.0mm Fixed, F=2.0, with IR Cut

Angle of View

Horizontal: 90°
Vertical: 45°

Pan/Tilt Angle

Horizontal: 355°
Vertical: 105°

Minimum Illumination

0 Lux (with IR Illuminator)

IR Distance

12 Meters (40ft)

Dimensions

103×95×117 mm

Weight (Battery Included)

380g

Interface

• Builtin microSD Slot

• Built-in Microphone & Speaker

• Reset Button

Software
Features

Protocols & Standards

SSL, TCP/IP, UDP, SMTP, DHCP, DNS, P2P

Image Compression

H.264

Maximal Frame Rate

15fps

Code Rate

768Kbps ~ 2048Kbps

Audio

Two-Way Audio

Maximal User Access

Up to 8 Simultaneous Live Streams

Browser Supported

Not Available

Access to Camera

Smart Phone: iOS, Android
Computer: Windows, Mac

Standby Awaken

PIR Alarm, Remote Access, Reset Button

Record Mode

PIR Alarm Record

WiFi

Wireless Standard

IEEE 802.11b/g/n

Operating Frequency

2.4 GHz

Wireless Security

WPA-PSK/WPA2-PSK

Battery

Battery Level Indication

Yes

Ordinary Life

4 - 6 Months

Endurance Ability

Daytime: 10 Hours, Night Vision: 5 Hours

Other
Parameters

Temperature

Operating Temperature : -10°C~+55°C
Storage Temperature: -40°C~70°C

Humidity

Operating Humidity: 20% ~ 85%
Storage Humidity: 10% ~ 90%

Waterproof

NO

PIR Sensor Hardware Features

Detecting Distance

8M (26ft)

Detecting Angle

Horizontal: 120°, Vertical: 60°

Transmitting Frequency

433MHz (Wireless)

Transmitting Distance

200M (Accessibility)

Battery Life

3 Years

Dimension

100x66.5x36.5 mm

Weight (Battery Included)

65 g

Temperature

Operating Temperature: -10°C~+55°C
Storage Temperature: -40°C~70°C

Humidity

Operating Humidity: 20%~85%
Storage Humidity: 10%~90%

Waterproof

NO

The above data are provided by internal laboratories, and are obtained under specific test conditions. Actual use may vary due to settings, use conditions and environmental factors.
