RLC-523WA

Smart 5MP PTZ WiFi Camera with Spotlight

Person/Vehicle Detection
Pan, Tilt & Zoom
2.4/5 GHz WiFi
Color Night Vision
Detect Smartly & Deter Actively
    • Person/Vehicle Detection
    • Accurate Alerts
    • Without Subscription
    • Built-in Siren
    • Motion Spotlight
    • Microphone
    • Speaker

Up & Down, Left & Right, Pinpoint & Track

With 360° pan & 90° tilt, this PTZ camera allows you to view your world from every angle and can follow the moving person automatically. Keep track of intruders and leave them nowhere to hide.

  • Auto Tracking
  • Manual Pan & Tilt

Marvelous Visual Experience Day & Night

Super High Definition (5MP)

RLC-523WA provides you with a clearer visual quality & smoother live viewing experience. You can stay better informed with the hard-to-see details captured by the camera.

This video was shared by Neil H. B., a Reolink customer.

This video was shared by Duane, a Reolink customer.

Super Clear Night Vision

RLC-523WA with infrared LEDs provides 190ft* IR night vision & its spotlights ensure color night vision. Ideal for outdoor areas that aren’t always well-lit.

  • 4 IR LEDs
  • Color Night Vision

5X Optical Zoom for More Visibility

Its motorized varifocal lens provides a wide viewing angle, and its 5X optical zoom allows you to zoom in for astonishing details or zoom out for maximum coverage.

27° - 96°

Viewing Angle*

2.74 mm - 13.5 mm

Motorized Lens

This video was shared by Robert C., a Reolink customer.

Time Lapse: Visualize the Passing of Time

Long-term events like sun rising and flower blooming is hard yet fun to observe. This PTZ camera with time lapse makes it quicker and easier to capture the dynamic of such events, with stunning effect.

* This feature is incompatible when camera is connected to NVRs.

Simple, Flexible & Durable

Dual-Band WiFi

RLC-523WA supports both 2.4 GHz and 5 GHz frequencies to ensure better performance for camera networking. One more choice, lots of conveniences.

2.4GHz/5GHz

Dual-Band WiFi

2T2R

MIMO Antennas

Wireless

Can be easily installed inside and outside your house. No messy cabling.

2.4 GHz Band & 5 GHz Band

More options available. No more sufferings from signal loss or interference.

2T2R MIMO Antennas

Stronger network signals, with operating range of up to 164 feet (in open areas).

Remote Access

With a few clicks on Reolink App or Client, you can stay tuned with your home or business all the time.

  • Real-Time Alerts Once it detects something suspicious, the camera will send to your device an instant push notification and an email with a detection snapshot. Know what’s happening all the time.
  • Live View from Anywhere Check your home situation when you’re on the journey, or see what’s up with your kids when you’re busy in the kitchen, with audio recording.
  • Easy & Smart Playback You can not only replay saved videos to find key information but also filter the video by detection modes and control the timeline to quickly locate what you want to see.
  • Motion Zone You can customize the motion zone to your like, deciding where objects’ movements will be detected and where they will not.

Flexible Storage Options

This smart IP camera supports 24/7 continuous, motion-triggered and scheduled recording. Videos can be saved into the microSD card, the Reolink NVR or the FTP server. Choose a way you like and enjoy easy and customized security.

microSD Card

Supports up to 256GB microSD card (not included).

24.2
hours

64GB

48.5
hours

128GB

97.1
hours

256GB

Figure based on the default bit rate of the cam (6144 kbps). Actual recording time depends on the settings. Results may vary. Learn more

Reolink NVR

If you want to save videos for much longer time or have multiple cameras to operate, connecting this camera to a compatible Reolink NVR or security camera system is a better choice.

*Reolink NVRs are recommended for best performance.

Waterproof Design

RLC-523WA is designed for use in multiple scenarios. Its IP66 housing can withstand powerful water jets, plus intense heat, humidity, and the cold.

RLC-523WA is designed for use in multiple scenarios. Its IP66 housing can withstand powerful water jets, plus intense heat, humidity, and the cold.

IP66 Certified Waterproof

Google Assistant
Alexa
Comparison

Comparison

What's in the Box What’s in the Box & Setup Guide (with Video) What's in the Box

*The data on the pages above are obtained under specific test conditions. Actual use may vary.

Comparison

*Data based on internal lab testing.

Specifications

Video & Audio

Image Sensor

1/2.7" CMOS Sensor

Video Resolution

Default: 2560 x 1920 (5.0 megapixels) at 20 frames/sec

Lens

f=2.7-13.5mm F=1.6-3.3, zoom module

Video Format

H.264

Field of View

• Horizontal: 27°-96°

• Vertical: 21°-69°

Day & Night

IR-cut filter with auto-switching

Infrared Night Vision

Up to 60 meters (190ft) (LED: 4pcs/28mil/850nm)

Color Night Vision

Spotlights: 3pcs/5700K/945 lumens

Audio

Two-way audio

Power

DC Power

DC 12.0V⎓2A, <24W

Interface

Power

DC power port

System

Reset button

Ethernet

One 10M/100Mbps RJ45

Storage

microSD card slot (Max. 256GB)

Audio

Built-in microphone and speaker

Pan&Tilt

Pan & Tilt Range

Pan: 360°, Tilt: 0°~90°

Pan Speed

2.5°-150°/s (speed can be set)

Tilt Speed

1.5°-60°/s (speed can be set)

Preset

64

Patrol

1 patrol; up to 16 presets per patrol

Auto Tracking

Support

Power-Off Memory Function

Support

Wi-Fi

Wireless Standard

IEEE 802.11a/b/g/n

Operating Frequency

2.4GHz/5GHz

Wireless Security

WPA-PSK/WPA2-PSK

Software Features

Frame Rate

• Mainstream: 2fps - 30fps (default: 20fps)

• Substream: 4fps - 15fps (default: 10fps)

Code Rate

• Mainstream: 1024Kbps - 8192Kbps (default: 4096Kbps)

• Substream: 64Kbps - 512Kbps (default: 256Kbps)

Browsers Supported

Edge, Chrome, Firefox, Safari

OS Supported

PC: Windows, Mac OS; Smartphone: iOS, Android

Smart Alarm

Person detection/vehicle detection/motion detection

Recording Modes

Motion recording (default)/scheduled Recording; 24/7 recording

Protocols & Standards

HTTP, HTTPS, SSL, TCP/IP, UDP, UPnP, RTSP, RTMP, SMTP, NTP, DHCP, DNS, DDNS, P2P, IPv4, FTP

Maximal User Access

Supports up to 12 simultaneous video streams (10 substreams & 2 mainstreams);
20 users (1 admin account & 19 user accounts)

Work with

Google Assistant

Working Environment

Temperature

Operating temperature: -10°C~+55°C (14°F~131°F)

Humidity

Operating humidity: 10% ~ 90%

Waterproof

IP66

Size & Weight

Dimension

Φ136 x 201mm

Weight

1.8kg

Warranty

Limited Warranty

2-year limited warranty. For support, visit https://support.reolink.com/hc/en-us/.

The above data are provided by internal laboratories, and are obtained under specific test conditions. Actual use may vary due to settings, use conditions and environmental factors.
