Reolink TrackMix LTE

Dual-Lens 4G PTZ Camera with Auto-Zoom Tracking

Wide-Angle & Telephoto Lenses
Dual View, Dual Tracking
2K 4MP Quad HD
4G LTE Network

TrackMix LTE

Dual Lens | Dual View | Dual Tracking

Super Wide & Super Clear

The wide-angle lens and the telephoto lens of the camera bring you a broad overview and a clear closeup simultaneously, and the two images are displayed on the same screen.

Follow It Automatically & Closely

TrackMix LTE can pan 355° and tilt 90° to automatically follow the moving object and display it in both wide-angle and close-up views.

What is dual-tracking?
Both on One Screen

No Wires, Less Hassle

Works on 4G & Battery Powered

Reolink TrackMix LTE is a dual-lens camera working on 4G LTE network. With battery or solar power, you can bring this camera to any place and enjoy its rich features, including smart detection, auto-tracking, two-way audio, and more.

Reolink TrackMix LTE Battery Powered Mobile Security Camera with Micro SIM Card

* Requires a Nano SIM card and a cellular data plan before use.

Supported carriers:

T-Mobile, Vodafone ...

Available countries and regions:

United States, Germany, United Kingdom, Italy …

See the full list Estimated data usage

Free from Wiring, Flexible to Anywhere

With rechargeable battery and solar panel, this camera realizes flexible power supply. You can install it easily and use it anywhere, even off-grid, using 4G network.

  • slider-alt-2
  • slider-alt-3
  • slider-alt-2
  • slider-alt-3
  • slider-alt-2

Crisp 2K Super HD Videos

With 2K 4MP high resolution, this dual-lens camera can capture sharper and finer details, bringing you a better visual experience.

The video was captured by the camera's wide-angle lens.

Smart Detection & Two-Way Audio

TrackMix LTE can distinguish people, cars and pets from other objects to provide you with more accurate alerts. In addition, the built-in microphone and speaker allow you to hear and talk to visitors in front of the camera in real time from anywhere.

Person/Vehicle Detection
Two-Way Audio
Pet Detection

Reolink

Person is detected from Reolink Camera.

Now

Two Night Vision Modes

The two infrared lights and a spotlight built in TrackMix LTE enable a clear night vision even at night. You can easily switch between the full-color and black-and-white images according to different situations.

  • 2 IR LEDs
  • Spotlight

Battery or Solar Powered

Eco-Friendly & Economical

Wire-Free Battery or Solar Powered Security Camera with Spotlight
Rechargeable Battery

With a long-lasting rechargeable battery, you can install Reolink TrackMix LTE wherever you want. No need for frequent battery changes or charges.

* The battery is non-removable.

Wire-Free Spotlight Wireless Security Camera
Solar Panel

This security camera can also be connected to a Reolink Solar Panel* for non-stop power. An eco-friendly solution with solar energy.

* Sold separately and designed for Reolink battery-powered cameras ONLY.

Time Lapse: A Fun Feature

The time lapse function can capture dynamic processes, such as sunrise and sunset, and accelerate them into minutes, allowing you to seize and view these stunning scenes.

* Note: Only the wide-angle view supports time lapse.

Stands Up to Harsh Weather

Be it pouring rain or scorching heat, this camera can work perfectly in a variety of environments, thanks to the sturdy and solid housing.

Local Storage on the microSD card

This security camera records motion-triggered events for later playback. You can save them locally on a microSD card (up to 128 GB).

Choose the right microSD card

Encrypted Cloud Storage

Event videos can be uploaded to the Reolink Cloud. The encrypted cloud service provides off-site backup of important moments and allows you to play back videos anytime anywhere.

Find the right Cloud plan for you

Coming Soon

Subscribe Subscribe

Thanks for your interest. For more updates,
@ReolinkTech on Facebook & Twitter.

Please enter a valid email address.

Server Error

Duplicate Submission. You have submitted successfully.
No need of repeated submission.

Submission Failed. Please try again later.

1
2
3

  • Accurate Real-Time Alerts

    This camera sends you real-time alerts when it detects something suspicious. You can configure when you want to enable notifications—all the time or on a specific schedule.

    • Push Notifications
      Check real-time alerts popping up on your smartphone.
    • Email
      Receive email alerts with snapshots taken on the spot.
    • Custom Siren
      Loudly warns you and powerfully deters intruders.

  • Live View & Smart Playback

    Via the free Reolink App/Client, you can easily click to check what's happening in your home or business and quickly search for the key evidence or funny moments.

  • Customizable Motion Zone

    You can customize the motion zone to your liking, deciding where where objects' movements will be detected and where not.

    • Motion Zone
Hey Google, show me the backyard.
Alexa, show me my front door.

Control Your Camera, Hands-Free

Alexa

As easy as saying "Hey Google, show me the Front Door", you can check what's happening there on your Google Nest Hub or Chromecast-enabled TVs.

Find how to connect Reolink to Google Assistant Note: Only the wide-angle view supports Google Assistant.

Control it with your voice. Just ask Alexa to show the video of your camera on the Echo Spot, Echo Show or Fire TVs, and everything is done.

Coming soon...

Four Versions Make It All Possible

The TrackMix series offers four versions—TrackMix PoE, TrackMix WiFi, TrackMix and TrackMix LTE—to meet all your needs. Indoors, outdoors, at home, or in business.

  • Power over Ethernet, Simplified Wiring & installation.

    TrackMix PoE

  • 2.4/5GHz Dual-Band WiFi, Smooth Networking.

    TrackMix WiFi

  • Battery or Solar Powered, Eco-Friendly and Economical.

    TrackMix

*Data based on internal lab testing.

Comparison

What’s in the Box & Setup Guide (with Video) What's in the Box

*The data on the pages above are obtained under specific test conditions. Actual use may vary.

Specifications

Download Specifications Download as PDF

Video & Audio

Image Sensor

1/3"CMOS Sensor

Video Resolution

Up to 2560 x 1440 (4.0 Megapixels) at 15 frames/sec

Lens

f=2.8mm@F=1.6，f=8mm@F=1.6

Video Format

H.264,H.265

Field of View

• Horizontal: 96°-38°

• Vertical: 55°-21°

Zoom Mode

6X hybrid zoom

Day & Night

IR-cut filter with auto-switching

Infrared Night Vision

Up to 30 Meters (100ft)(LED: 2pcs/850nm)

Color Night Vision

Spotlight: 1pcs/6500K/450 Lumens

Audio

Two-way audio

Power

Battery

7.2V 5100mAh rechargeable battery (battery life varies, based on settings, usage & temperature);
36.72Wh(Power capacity)

Solar

Reolink Solar Panel 2

DC Power

5V/2A

Interface

Power

USB Type-C port

System

Reset button

Storage

Micro SD card slot (max. 128GB)

Audio

Built-in microphone and speaker

Pan & Tilt

Pan &Tilt

Pan: 355°, Tilt: 0°~90°; (Speed can be set)

Preset

32

Auto Tracking

Support

3G/4G

Frequency Bands

• Europe version:
LTE FDD: B1/B3/B7/B8/B20/B28A
WCDMA: B1/B8

• USA version:
LTE FDD: B2/B4/B5/B12/B13/B14/B66/B71

• Australia version:
LTE FDD: B1/B3/B5/B7/B8/B28
WCDMA: B1/B5/B8

Transmission Data

• LTE FDD: Max 10Mbps(DL), Max 5Mbps(UL)

• LTE TDD: Max 8.96Mbps(DL), Max 3.1Mbps(UL)

• HSPA+: Max 42Mbps(DL), Max 5.76Mbps(UL)

• UMTS: Max 384Kbps(DL), Max 384Kbps(UL)

Software Features

Frame Rate

• Mainstream: 10fps - 15fps

• Substream: 10fps - 15fps

Code Rate

• Mainstream: 1024Kbps -4096Kbps

• Substream: 64Kbps -512Kbps

OS Supported

PC: Windows, Mac OS; Smartphone: iOS, Android

Smart Alarm

PIR detection/person detection/vehicle detection/pet detection

Record Mode

Motion-triggered recording

Protocols & Standards

SSL, TCP/IP, UDP, UPNP, SMTP, NTP, P2P

Maximum User Access

Support up to 12 simultaneous video streams (10 substreams & 2 mainstreams)

Work with

Google Assistant, Reolink Cloud

Working Environment

Operating Temperature

-10°C~+55°C (14°F~131°F)

Operating Humidity

20% ~ 85%

Waterproof

IP65

Size & Weight

Dimension

228.2*147*129mm

Weight

1.4KG

Warranty

Limited Warranty

2-year limited warranty. For support, visit https://support.reolink.com/hc/en-us/

More
The above data are provided by internal laboratories, and are obtained under specific test conditions. Actual use may vary due to settings, use conditions and environmental factors.
