RLC-842A

4K PoE Cam with Intelligent Detection & 5X Optical Zoom

Person/Vehicle Detection

4K 8MP Ultra HD

IK10 Vandal Proof

Audio Recording

Overview
Comparison
Accessories
Video
Specs
FAQs
Review

Smarter Detection & Superior Protection

Intelligent Detection: Focuses on What Matters

Equipped with person/vehicle detection and pet detection (beta)* technology, RLC-842A can smartly discern the shapes of people, vehicles, and pets*. Trivial objects’ movements will be ignored so as to reduce false alarms. You can always get accurate alerts about important events.

*Note: Currently, the pet detection is in beta testing and can only identify dogs and cats.

Person/Vehicle Detection

Accurate Alerts

Without Subscription

Pet Detection (beta)*

Reolink

Person is detected from Reolink Camera.

Today

5X Optical Zoom: See Closer & Clear

With a motorized varifocal lens, RLC-842A provides a wide viewing angle of 27°~96°. Its 5X optical zoom allows you to zoom in for astonishing details and zoom out for a broader perspective.

27° - 96°

Viewing Angle*

2.7 mm - 13.5 mm

Motorized Lens

4K Ultra HD: Impressive Clarity & Sharpness

Home security jumps to a higher level with 4K 8MP Ultra HD. You can clearly see what’s happening from the camera, and more importantly, you can enjoy the flawless pictures and videos. Even the hard-to-see details won't be lost.

This video was shared by Mike M., a Reolink customer.

Sleepless Guard with Night Vision

RLC-842A always keeps your family guarded day and night. This 4K security camera is equipped with 24 infrared LEDs, allowing you to see things clearly even in the darkness within the range of up to 100ft.

24 IR LEDs
Up to 100ft*

This video was shared by Portal N., a Reolink customer.

Time Lapse – See the Day in a Minute

Long-term events like sun rising and flower blooming are hard yet fun to observe. This camera with time lapse makes it quicker and easier to appreciate the amazing process of such events in minutes.

* This feature is incompatible when camera is connected to NVRs.

Multiple Recording Options

This smart IP camera supports 24/7 continuous, motion-triggered, or scheduled recordings. All the videos can be saved to the micro SD card, Reolink NVR or FTP server. Choose a way you like and enjoy customized security.

Micro SD Card

Supports up to 256GB micro SD card (not included).

24.2
hours

64GB

48.5
hours

128GB

97.1
hours

256GB

Figure based on the default bit rate of the cam (6144 kbps). Actual recording time depends on the settings. Results may vary. Learn more

Reolink NVR

If you want to save videos for much longer time or manage multiple cameras, you can simply connect the camera to a compatible Reolink NVR or security camera system.

* Reolink NVRs are recommended for best performance.

Check its compatible NVRs

Customize your security camera system

Easy Installation & Control

PoE — Faster, Easier & Lower-Cost Installation

Thanks to Power over Ethernet (PoE) technology, this IP camera can transmit videos and be charged simultaneously via only one single network cable. You can install this camera quickly and nicely.

Plug & play
Reliable connection

Compare with the Non-PoE Camera

PoE Camera
Only needs a network cable

Non-PoE Camera
Needs both a network cable and a power adapter

IK10 Vandal-Proof

Being IK10 vandal-proof means that this camera is tougher to withstand outside damage. Its lens is well protected by the heavy-duty housing and avoids being harmed when something accidentally hits the camera or someone attempts to destroy it.

Fearless of Any Harsh Weather

RLC-842A can be used in various conditions, whether indoors or outdoors. The rugged body and housing enable this camera to withstand powerful water jets, intense heat, humidity, and the cold.

IP66 Certified Weatherproof

Remote Access & Control

Reolink App & Client are great for you to quickly configure the camera and make full use of its magnificent functions.

8MP PoE Smart Home Outdoor Indoor IP Camera

Download Reolink App & Client

Real-Time Alerts When the camera detects something suspicious, it will immediately send real-time alerts to your device with a snapshot so that you can take quick action.

Live View from Everywhere Wherever you are, you can always know what's going on in your home with live video and audio. Take your phone when going out and everything is under control.

Easy & Smart Playback Replaying recordings is so easy when you locate them by date and timeline. Sharing fun moments or keeping crucial evidence, you won't miss any important events.

Customized Motion Zone Your privacy is highly valued. You can freely customize the motion zone by masking out the area where you don't want the camera to detect motions.

*Data based on internal lab testing.

Google Assistant

Alexa

Control Your Cameras, Hands-Free

It can’t be easier to control this camera with Google Assistant. Just say “Ok Google, show me the backyard” and the live feed will appear on your Google Nest Hub or Chromecast-enabled TVs.

Coming Soon

* This feature is incompatible when camera is connected to NVRs.

Control Your Cameras, Hands-Free

Alexa-enabled RLC-842A allows you to control it with the voice. Just ask Alexa to show the video of your camera on the Echo Spot, Echo Show or Fire TVs, and everything is done.

Coming Soon

* This feature is incompatible when camera is connected to NVRs.

What’s in the Box & Setup Guide (with Video) What's in the Box

*The data on the pages above are obtained under specific test conditions. Actual use may vary.

Gallery & Specs

1Metal Aluminum Case

2IR LEDs

3High Definition Lens

4Daylight Sensor

You can manually rotate it to get the best monitoring angle.

1Power

2Reset Button

3Network

4Waterproof Lid

Specifications

Download as PDF

Video & Audio

Image Sensor

1/2.8" CMOS sensor

Video Resolution

Default: 3840 x 2160 (8.0 Megapixels) at 25 frames/sec

Lens

f=2.7-13.5mm; F=1.6-3.3

Optical Zoom

Video Format

H.265

Field of View

• Horizontal: 96°-27°

• Vertical: 69°-21°

Day & Night

Auto-switching

Night Vision

30 Meters (100 ft) (LED: 24pcs/14mil/850nm)

Audio

Audio recording

Power

POE

IEEE 802.3af, 48V Active

DC Power

DC 12.0V⎓1A, <12W

Interface

Power

DC power port

System

Reset button

Ethernet

One 10M/100Mbps RJ45

Storage

Micro SD card slot (Max. 256GB)

Audio

Built-in microphone

Software Features

Frame Rate

• Mainstream: 2fps - 25fps (default: 25fps)

• Substream: 4fps - 15fps (default: 10fps)

Code Rate

• Mainstream: 4096Kbps - 8192Kbps (default: 6144Kbps)

• Substream: 64Kbps - 512Kbps (default: 256Kbps)

Browser Supported

Edge, Chrome, Firefox, Safari

OS Supported

PC: Windows, Mac OS; Smartphone: iOS, Android

Smart Alarm

Motion detection; person detection; vehicle detection; pet detection (beta)

Record Mode

Motion-triggered recording (default); scheduled recording; 24/7 recording

Protocols & Standards

HTTPS, SSL, TCP/IP, UDP, HTTP, IPv4, UPnP, RTSP, RTMP, SMTP, NTP, DHCP, DNS, DDNS, FTP, P2P

Maximal User Access

20 users (1 admin account & 19 user accounts); Support up to 12 simultaneous video streams (10 substreams & 2 mainstreams)

Smart Home

Google Assistant

Working Environment

Temperature

Operating temperature: -10°C~+55°C (14°F~131°F)

Humidity

Operating humidity: 10% ~ 90%

Waterproof

IP66

Size & Weight

Dimension

Φ133*100.25mm

Weight

686g

Warranty

Limited Warranty

2-year limited warranty. For support, visit https://support.reolink.com/hc/en-us/

The above data are provided by internal laboratories, and are obtained under specific test conditions. Actual use may vary due to settings, use conditions and environmental factors.
